8 Rotor Agriculture UAV has the advantages of designed with fireproof, rainproof and dustproof - Extremely light weight, maximum capacity of up to 8L/10L(10kg)
Contact Us Product Center
- 8 Rotor Agriculture UAV designed with fireproof, rainproof and dustproof
- Extremely light weight, maximum capacity of up to 8L/10L(10kg)
- Plug structure design with tapered arm, convenient replacement and maintenance
- Loose connection design patent, assembly and disassembly without tool
- High stability power device, dynamic power redundancy
- GPS hover, pointing flight and automatic route flight function
|
Specification |
Model:FH-8Z-5 |
|
Size(L*W*H) |
1150*1150*500mm |
|
Aircraft folding size |
435*435*500mm |
|
Aircraft weight |
7kg |
|
Maximum takeoff weight |
14kg |
|
Aircraft pesticide load |
5kg |
|
Propeller |
15 inch carbon fiber plant protection special propeller |
|
Spraying task system |
1 sets of kit, dispersion spray system, booster pump |
|
Remote control |
2.4G Nine channel |
|
Power battery |
High performance lithium polymer lithium battery (22.2V/16000mA) |
|
charger |
High power lithium battery balance charging equipment (can charge 2 pcs at the same time, half an hour full) |
|
UAV self stabilization system |
yes |
|
Spraying system |
Diffuse atomization nozzle (a group of *6) |
|
Motor speed |
1200rpm/min |
|
Aircraft endurance time |
10～15min |
|
Spraying height |
Field operation 0-200 M |
|
Spraying area |
4 meters |
|
Control efficiency |
1～3 acre/min |
|
Spray flow |
0.25-0.75L/min(multi nozzle) adjustable |
|
Flying speed |
0 -8meter/second(can be adjusted according to needed speed) |
|
Flying height |
0～200meter |
|
Hover |
Arbitrary position direction air hover |
|
Flight attitude |
Flying in any direction, can be reversed to fly, emergency brake |
|
Takeoff / landing time |
≤1minute |
|
Body material |
Carbon fiber |
|
Temperature range |
-15℃～40℃ |
|
Battery power performance |
charge-discharge 300-500 times |
|
Rack life |
≥5 years |
|
Maximum efficiency |
200-300acre/day |
