Diesel Engine Drive Pellet Mill

Introduction of Diesel Engine Drive Pellet Mill

Diesel Engine Drive Pellet Mill is powered by diesel engine, which can be used under the condition without power supply. This type Diesel Engine Drive Pellet Mill is widely used in the medium and small farm, feed processing factory and small private business...etc. With production capacity range from 60kg to 250kg per hour, it can be used to process with corn, soybeans, wheat, stalk, rice husk, straw powder...etc.

The animal feed produced by Feed Pellet Mill Driven by Diesel Engine can imporve the nutrition digest efficiency of animal. It can also kill the pathogenic microorganisms and parasites.This kind pellet feed is an ideal feed for rabbit,cattle, goat,dog, pig, duck, chicken, fish and the other small animal. Usually the pellet size of the Feed Pellet Making machine is range from 3mm to 6mm, which can be used to produce different animal feed and achieve the best feeding effect.The roller is the key parts of the pellet mill. By adopting high quality alloy steel as material,the pellet mill life has been highly improved.

Features of Diesel Engine Drive Pellet Mill

1. Designed with diesel engine
2. High output capacity, continuous work
3. Easy operation and convenient for maintenance

Parameter of Diesel Engine Drive Pellet Mill

Model	Capacity for wood pellets	Capacity for feed pellets	Power (HP)	Diameter of mould
WHSD-120D	30-50kg/h	50-80kg/h	8HP	120mm
WHSD-150D	80-100 kg/h	100-150kg/h	8HP	120mm
WHSD-200D	100-150 kg/h	200-250kg/h	15HP	200mm
WHSD-230D	150-180 kg/h	250-300kg/h	22HP	230mm
WHSD-260D	180-230 kg/h	300-400kg/h	30HP	260mm
WHSD-300D	250-300 kg/h	400-500kg/h	55HP	300mm
WHSD-360D	300-400kg/h	500-600kg/h	55HP	360mm
WHSD-400D	400-450kg/h	600-700kg/h	55HP	400mm

Pictures of Diesel Engine Drive Pellet Mill

PHOTOS OF

Diesel Engine Drive Pellet Mill

•
