This water well drilling machine used for general investigation, geophysical exploration, high-way and building construction, and blast-hole drilling etc. With hydro-automatic feeding device, and high
Contact Us Product Center
This water well drilling machine used for general investigation, geophysical exploration, high-way and building construction, and blast-hole drilling etc. With hydro-automatic feeding device, and high drilling efficiency.
Designed with hydro-chucking unit instead of slips to ensure drilling from stop when changing pipes . Close levers, convenient to operate, safe and reliable operation . Compact in structure.
All the drill, water pump and diesel engine installed on one base frame result in space-saving . Light in weight, easy disassembling for transportation and applicable to working conditions in plain and mountain areas.
|
1.Unity Machine Parameter |
|
|
Drilling Depth(m) |
60~300m |
|
Max. Open Hole Diameter(mm) |
260 |
|
End Hole Diameter(mm) |
75 |
|
Drill Rod Diameter |
50mm |
|
Drilling Angle |
90~75 |
|
Drill Weight (No include power) |
810kg |
|
Overall Dimension |
2500*900*1300mm |
|
2.Spindle |
|
|
Spindle Speed |
142,285,570r/min |
|
Spindle Stroke |
450mm |
|
3.Hoist |
|
|
Max. Single Line Hoisting Capacity |
960kg |
|
Reel Lifting Speed |
0.41,0.82,1.64m/s |
|
Tightrope Diameter |
10mm |
|
Tightrope Cubic Measure |
27mm |
|
Hug Follgate Belt Width |
70mm |
|
4.Mud Pump |
|
|
Type |
Horizontal Single Urn Twin-action |
|
Discharge/Displacement |
95/77L/Min. |
|
Diesel |
S1105 18HP |
|
Electric Motor |
11KW,1440r/min |
|
Max. Pressure |
1.2Mpa |
|
Work Pressure |
0.7Mpa |
|
Water Inlet Diameter |
30mm |
|
Water Outlet Diameter |
25mm |
|
Triangle Conveyre Belt |
B1575mm |
