The agricultural grinder has the characteristics of reasonable design, compact structure, efficient energy saving system, safe and reliable hydraulic system, easy to use, small working radius, quick l
Contact Us Product Center
| Grass Grasping Machine | |
| model | TZM20 |
| type | rubber-tyred, slink |
| engine power | 47 kW |
| engine speed | 2400 r/min |
| length*width*heigth(with cab) | 5750*1750*2870 mm |
| front/rear wheel tread | 1480/1480 mm |
| wheel base | 2100 mm |
| total weight | </=4800 kg |
| minimum turning radius | 6000 mm |
| gradeability | 20 degree |
| minimum ground clearance | 240 mm |
| speed | 0--22 km/h |
|
hydraulic system working Device form and set pressure |
gear pump 16 MPa |
| Smooth lift height | >/= 3500 mm |
| dumping reach | 1150 mm |
| hoisting time | </=8 s |
| the time of four movements | </=20 s |
| the rated load volume/capacity | >/= 1.2 m3/1000kg |
| maximum turning angle | >/= 20 degree |
